Product Features:

• Comes with a Metal Cabinet
• Built-in AT&T LTE Cellular Communicator (powered by Alarm.com)
• 8 wired zones on board (expandable up to 128)
• MX Addressable loop for 124 MX devices
• Supports Wireless 433 MHz Security RF Sensors
• Support PowerG 915 MHz Encrypted Sensors
• Up to 128 wired/PowerG/MX zones
• Up to 8 partitions
• Up to 1000 users
• Interactive services powered by Alarm.com give you mobile apps on any platform and enable powerful features like geo-fences, scenes, and notifications
• Dual path connectivity uses WiFi and AT&T LTE simultaneously for speed, flexibility and redundancy
• Native LTE/Wi-Fi/Bluetooth LE/Ethernet/Z-Wave
• Control your entire home with the built-in Z-Wave 700 Series radio that securely connects to lights, locks, thermostats, garage openers and more
• 16GB NAND flash internal storage
• IQ Installer allows fast and easy installation
• IQ Remote WiFi/PG supported

• IQ Remote PG
• HSM3105 MX Addressable interface
• LCD keypads HS2LCD, HS2LCDP, HS2ICN, HS2ICNP
• Zone expanders (HSM2108)
• PGM Expanders (HSM2208 & HSM2204)
• Power Supplies (HSM2300)
• PG Host with auto-switch PowerG from onboard to Host, once enrolled

General Information

• Dimensions (L x W x D): 19" x 12"W x 4.9"D (482.5mm x 305mm x 124mm)
• Weight: 9.8 lbs (without battery)
• Operating Temperature: -10°C to 55°C (14°F to 131°F)
• Humidity: 5% to 93% RH non-condensing
• Users: Up to 1000 users (Soft Lauch limited to 249)
• User Types: Master, installer, dealer, guest, duress and user codes (4 or 6-digit codes)
• Partitions: Up to 8 partitions
• Wired Keypad Support: Up to 16 hardwired keypads
• Wireless Keypad Support: Up to 5 wireless Keypads including IQ Remote PowerG
• System Supervision: AC, zone, fire, communication, low battery, RF jam, Aux, module, system troubles/faults
• Communicator Support: Dual communicator support, using onboard wifi or Ethernet, secondary communication using built-in cellular radio
• Remote Services: Alarm.com integration, cloud connectivity
• Central Station Reporting: Central station reporting through Alarm.com using SIA or CID
• Local Programming: On Smartphone using the local installer interface connected on Wi-Fi
• Event History: Captures, stores and reports up to 200 events
• Certification: FCC, IC, UL-985, UL-1023, UL-2610 UL-1637, ULC-S545, ULC-S304
• Processor: Qualcomm SnapDragon 8 Core SOM (System On a Module) with 16 GB of NAND Flash
• WiFi Network: Wi-Fi 802.11 a/b/g/n/ac dual band 2.4/5ghz - including built-in router capability
• Ethernet Network: Ethernet 10/100Mb
• Cellular Network: Verizon Cellular LTE CAT4 (Bands 2/25, 4/66, 5/26, 7, 12/17, 13, 14 (non-First Net)

Power Sources

• External Power Supply Adapter: 120VAC, 60Hz, 1.2A
• Power Supply DSC UL and ULC Models: HS40WPSA & HS40WPSNA
• Additional Power Supply: Up to 4 Additional Power Supply (HSM2300 or HSM 2204)
• Battery Type: Sealed, rechargeable lead acid
• Current Draw (Control Panel): 120 mA (nominal)

Connectivity

• Zone Configuration: Up to 128 Sensors (fully supervised)
• Zone Groups: Up to 41 sensor groups
• Addressable Zones: Up to Panel Max using HSM3105 Expander for MX addressable technology
• Hardwired Zone Types: Normally Closed, Normally Open, SEOL, DEOL
• Hardwired Zones: 8 zones on board Expandable to Panel Max using HSM2108 up to Panel Max
• PowerG Wireless Zones: 915 Mhz Long Range Secure Encrypted 2-Way Wireless (PowerG radio modem operates in 912-919 MHz band long range, secure encrypted two-way wireless)
• Security RF Wireless Zones: Depending on the model: Either S-Line Encrypted 319.5 MHz, 345 MHz, or 433 MHz (Soft Lauch, only 433 available)
• Wireless Keys: Supports up to 32 wireless remote keys
• Panic Pendant: Up to 120
• Programmable Outputs: 4 onboard, 128 low current using HSM2208, 16 high current using HSM2204
