SLE-MAXA-Z - Napco StarLink Max Connect Universal Dual-Path Internet/Cellular AT&T 5G LTE-M Alarm Communicator with Z-Wave Control (Compatible with Most Panels)

SLE-MAXA-Z - Napco StarLink Max Connect Universal Dual-Path Internet/Cellular AT&T 5G LTE-M Alarm Communicator with Z-Wave Control (Compatible with Most Panels)
SLE-MAXA-Z - Napco StarLink Max Connect Universal Dual-Path Internet/Cellular AT&T 5G LTE-M Alarm Communicator with Z-Wave Control (Compatible with Most Panels)
Item# SLE-MAXA-Z
List Price: $340.18
Pre-Order: $226.79
Availability: In Stock
QTY:
Shipping3-5 Business Days
Returns30-Day Return Window
PaymentSecure Transaction

Please Note: The Napco SLE-MAXA-Z StarLink Max Connect universal dual-path internet/cellular AT&T 5G LTE-M alarm communicator with Z-Wave control is a special order item.

Napco SLE-MAXA-Z Product Description:


The Napco SLE-MAXA-Z StarLink Max Connect is a universal dual-path (IP/Cellular AT&T 5G LTE) alarm communicator, with Z-Wave automation control, that is designed for new or existing security systems. Napco's SLE-MAXA-Z is a reliable takeover device, that upgrades legacy security platforms to a modern, mobile experience. Much more than a basic communicator, this intuitive device smartly bridges intrusion security with a full emulated remote keypad, bus data and full notifications. The StarLink Max Connect is a multi-function Commercial Burglary and Residential Fire alarm communicator that function as supervised system interface modules.

Using the SLE-MAXA-Z you can stay connected all the time to your home or business. From any smart device you can keep an eye out on one property or many, get text or video notifications on events, on virtually anything, like temperature alerts, refrigerator door ajar/open, deliveries, scheduled events that did or didn't happen, alarms, video-verified openings/closings and more. See status and take charge of your smart security system, which can include, cameras, thermostats, lighting & locking, set on a whim, on schedule, or grouped together as a scene. Add video monitoring and automatic video alerts and keep in touch with your home or business. With the SLE-MAXA-Z you can virtually be in two places at once. Keep in touch with your home, look in on kids, pets or parents, etc. Get video, as if you're there, in the event an alarm happens; or, if something doesn't happen, like a child not returning from school when expected, or elders not journeying out, etc.

The Napco iBridge App keeps you actively connected and in charge. By having a SLE-MAXA-Z communicator installed you'll have remote full system management controls, a virtual keypad that matches the one on the wall; you can add or remove staffers and permissions; assign access codes; allow temporary late-night delivery access. If a door is opened or left open. If there's an alarm and the police respond. If someone arms or disarms your home security system - as usual, or unexpectedly, you'll know who and when. Users receive notification alerts about changes in the alarm system on their mobile devices. These notifications are sent via iBridge Messenger SMS text messages and/or emails, keeping both users and dealers informed of system status changes.

Keep your property safe with 24/7 professional alarm monitoring services by GeoArm Security. For new systems or adding on to existing ones, StarLink Max Connect® not only provides smart business management control and convenience, but it also links your system to GeoArm's central alarm monitoring station wirelessly. The SLE-MAXA-Z utilizes today's fastest multibillion dollar cyberprotected AT&T cellular 5G LTE network, instead of relying on phone lines that can be gone, cut or down.

StarLink SLE Series communicators use proprietary data-capture technology that captures the alarm report from the control panel and transmits the alarm signals to the SLE Control Center (the Napco "NOC"); the alarm signals are then forwarded to ANY central station via Contact ID or 4/2 via DACT from the NOC, or to the Napco Virtual IP Central Station Receiver (NCSR), or Sur-Gard System II, Sur-Gard System V, Bosch D6100IPV6 or Bosch D6600 Receiver (with ITS-D6686 Ethernet Adapter) via TCP/IP using standard line security. The SLE Control Center reports a trouble signal in the event that the network does not receive the expected supervision signal from the wireless communicator. In addition, both StarLink communicator models can be powered directly from the control panel.

Armed with the SLE-MAXA-Z, end-users can cut install time and simplify operations. The SLE-MAXA-Z communicator include two antennas. Only one antenna is active at a time, and should the communicator have a loss of adequate signal strength, the communicator will connect to the tower via the other antenna. The StarLink Max Connect is easy-to-install, and is broadly compatible with common panels, such as Honeywell® and DSC®, giving existing systems a game changer upgrade for the 15-Million older panels online today. Provides a monitoring pathway to the GeoArm central station via a digital CAT-M1 communicator (compatible with AT&T) and can optionally connect to the Internet through a TCP/IP network using a wired Ethernet connection or an optional Wi-Fi adapter (note: Wi-Fi is not utilized for commercial burglary).

Product Features:

  • Simplest 4-Step, 4-Wire alarm communicator installation and easiest activation - real equipment cost savings with 5-in-1 functions from one unit. Just Enter a Radio ID. Napco Auto-Dialer Capture completes all (no entering phones nos., formats, account nos.). Requires No Internet Connection at Premises. Please Note: Video requires internet connectivity.
  • Upgrade to StarLink Max Connect from old radios, networks, POTS, landlines or new installs/new construction - provides the very latest features & the smart phone remote interactive control today's consumers want at a fraction of the cost (growing list of major brands, i.e., Honeywell, ADT, DSC, Napco)
  • Use with your choice of favorite panel brand(s) and any central station - NO special equipment.
  • Signal boost and dual diversity antennae - Signal Boost™ Circuitry and unique dual-diversity twin antennas, maximizing signal acquisition and eliminating the multiphase-effect signal-clash/ drop-outs single-antenna units are prone to.
  • Smart remote virtual keypad and SMS/MMS text and live video notifications - using any/all keypad-bus activities and events powered by Gemini App (Apple Store® & Google Play®).
  • Ideal upgrade path for integrating IP video - IP Video Cameras (for inside or outdoors) and/or Video Doorbell with two-way voice thru the App.
  • Full event reporting from any panel - anywhere field-proven to work virtually anywhere in North America, on Panels using Contact ID or 4/2.
  • Full up/downloading of top panel brands - Honeywell, DSC, Napco; plus, hand programming of them too via Virtual Keypad App, also including ADT®.
  • Full high-speed Napco panel up/downloading - Remote super-speed uploading/ downloading, requires cable, SLE-DLCBL.
  • WiFi Option - Add optional plug-in module and eliminate a CAT5 cable run for connectivity.
  • Built-in Z-Wave device control hub for connected home/business and scenes - uses standard Z-Wave Devices (includes the SLE-ZWAVE-MOD).
  • Compatible with most 12VDC alarm control panels - including the NAPCO Gemini series (GEM-P816, P1632, P1664, P3200, P9600, X255), as well as Honeywell and DSC panels.

Napco SLE-MAXA-Z Product Specifications:


General Specs for Standard Model

  • Housing: Durable ABS plastic (white) includes three keyhole slots for mounting (easy alignment with triple gang boxes)
  • Housing Dimensions (H x W x D): 5-3/8" H x 7-7/8" W x 1-7/8" D
  • Weight: 13.5 oz
  • Diagnostic LED Indicators: Three (3): Green, Signal Strength; Amber-Busy/ Activation; Red-Trouble
  • Operating Temperature Range: 32°F to 120°F (0°C to 49°C)
  • Operating Humidity: Maximum 93% (non-condensing)
  • Input Voltage: 11-15VDC (all models are power-limited output from control panel)
  • Input Current: standby current: 100mA (110mA with telco EOLR)


Electrical Ratings for the 1 Burg/Fire Input

  • Input Voltage: 9-15VDC
  • Maximum Input Current: Up to 2mA from control panel supply circuit


Electrical Ratings for the IN 2 and IN 3

  • Maximum Loop Voltage: 15VDC max
  • Maximum Loop Current: 1.2mA
  • End of Line Resistor (EOLR) Value: 10K


Electrical Ratings for the 3 PGM Outputs

  • Open Collector Outputs: Maximum Voltage 3V when active; 15V maximum when not active
  • Maximum PGM Sink Current: 50mA (up to 15VDC)

Napco SLE-MAXA-Z Product Compatibility:


• ADT Brand
• Honeywell Brand
• DSC Brand
• Napco Brand
