Product Features:

• 7" capacitive touchscreen with intuitive swipe/scroll/touch-based user interface
• Built-in AT&T LTE Cellular Communicator
• 5MP panel camera capable of capturing disarm photos and alarm videos and sending them to your phone
• Qualcomm Snapdragon chipset includes quad core processor, LTE, WiFi ac, built-in router, Android 5 OS
• Cloud token authentication ensures all processes are truly secure
• S-Line secure 319.5 radio connects to authenticated sensors putting security back into security
• Bluetooth touchless disarming allows you to pair up to five smartphones for secure, authenticated disarming without taking your phone out of your purse
• Built-in panel Glass Break uses microphones and complex algorithms to detect the sound of breaking glass
• Interactive services powered by Alarm.com give you mobile apps on any platform and enable powerful features like geo-fences, scenes, and notifications
• Dual path connectivity uses WiFi ac and LTE simultaneously for speed, flexibility and redundancy
• Panel turns into a customizable photo frame when not in use
• Over the air software updates ensure your panel always has the latest and best features available
• Control your entire home with the built-in Z-Wave Plus radio that securely connects to lights, locks, thermostats, garage openers and more
• Built-in microphones and speakers allows you to talk directly to your monitoring station agent from the panel (where available)
• MicroSD card slot allows you to customize your photo frame or save photos taken by the panel camera and put them on your computer
• On screen video tutorials make self-service easy and fast with videos on the most common issues
• Message Center allows you to get messages about your system or from GeoArm

• Dimensions: 5"H x 7.75"W x 0.75"D (195mm x 130mm x 23mm)
• Platform Android OS: Android 5.1
• LCD Display Size: 7 inch LCD
• LCD Display Resolution: 1280 x 800
• LCD Display Brightness: 300 cd/m2
• LCD Display RGB: 24bit
• Touchscreen Type: Capacitive glass multi-touch
• User Codes: Up to 242 Role-based (Dealer, Installer, Master, User, Guest, Duress)
• Wireless WiFi: WiFi 802.11 a/b/g/n/ac dual band 2.4/5G - including built-in router capability
• Wireless Image Sensor: Proprietary Image Sensor capable of pairing with up to 5 devices
• Wireless Z-Wave Plus: 119 total (Up to 80 lights, up to 6 locks, up to 6 thermostats, up to 6 garage doors, up to 21 misc)
• Wireless Cellular: AT&T LTE
• Wireless Security R/F: S-Line Encrypted 319.5 MHz, up to 128 security zones
• Wireless Bluetooth: Bluetooth Low Energy (BLE) 4.0
• Radio Slots: Fits up to 4 replaceable radios
• Hardwire Input Wired x2: Wired x2 Non-powered, closed loop circuit
• Siren Output Wired x1: Wired x1 Control output only (open collector)
• Flash Memory Internal Storage: 8GB NAND Flash
• SD Card Slot Push-Push: Micro SD x1
• LED Indicator Status LED: Single 3 color LED (green/yellow/red)
• Speaker Stereo 1W x 2: Stereo speakers (unified audio system)
• Front Camera: 5MP fixed focus
• Microphone: Stereo microphones
• Internal Siren Piezo: SPL minimum 85dB for UL985
• Tamper Switch: Panel tamper switch with spring release and reporting to status app
• Battery Type: Lithium Polymer 3200mAh
• Hard Buttons: Single wake button, all user controls through touch interface
• Power Supply DC: 5v - 5.5v 1000mA DC adapter, Input 100-240VAC 50/50Hz
• Mount Back Plate: Wall mount or table top (stand included)
• Certification FCC: 2AAJXQSIQPANEL2 (may contain additional modules with separate FCC IDs)
• Certification IC: 11205A-QSIQPANEL2
• Certification UL: UL-985, UL-1023, UL-1635, UL-639, UL-498A, UL-634, ULC-634, ULC-S306, CSA-C22.2
• Operational Temperature: -10°C to 50°C
• Storage Temperature: -40°C to 80°C
