5897-35 - Honeywell Wireless Dual-Tec Motion Detector
Please Note: The Honeywell 5897-35 wireless dual-tec motion detector has been discontinued and replaced by the 5898 wireless dual tec motion detector.
Honeywell 5897-35 Product Description:
The Honeywell 5897-35 is a wireless Dual-Tec motion sensor provides reliable detection with improved false alarm immunity for tough commercial environments. The 5897-35 is a great addition to any Honeywell wireless LYNXR-2, L3000, L5000 control panel or other compatible Honeywell security system. Used in installations where severe temperatures or temperature fluctuations exist.
Product Features:
- Dual technology - microwave 2.45GHz and dual element passive infrared detection method
- Microwave range adjustable
- Automatic walk test mode - enabled by opening/closing cover
- Temperature compensation adjusts for ambient temperature for improved performance
- Microwave range adjustable
- Microwave technology supervision
- Optional pet alley (35' x 30') and included barrier lenses (35' x 11')
- Case tamper protection
- User replaceable, long life lithium battery
- Backed by Honeywell's 2-year limited manufacturer's warranty
Honeywell 5897-35 Product Documents:
• Data Sheet for Honeywell's 5897-35 Wireless Dual-Tec Motion Detector
• Installation/Setup Guide for Honeywell's 5897-35 Wireless Dual-Tec Motion Detector
Honeywell 5897-35 Product Specifications:
- Dimensions (W x H x D): 2.875 x 5.0 x 2.313 (in), 7 x 13 x 6 (cm)
- Batteries: (4) CR123A, 3V lithium batteries (included)
- Battery Life: 3 years (normal use)
- Coverage: 35 x 30 (ft), 11 x 9 (m)
- Detection Zones: 24 Zones
Long Range Zones - 11
Intermediate Zones - 7
Lower Zones - 4
Look-Down Zones - 2 - Detectable Walk Sensitivity: 2-4 steps
- PIR White Light Immunity: >4000Lux
- RIF Immunity: 30V/M, 10-1000MHz
- Mounting Height: 7.5ft (2.3m)
- Transmit Frequency: 345MHz
- Operating Temperature: 32° to 140°F (0° to +60°C)
- Operating Relative Humidity: Up to 95% (non-condensing)
- Wireless Range: Up to 200ft
- Compatibility: All Honeywell 5800 Series wireless receivers, VISTA and LYNX alarm control panels
- Approvals: FCC, IC, UL intrusion-detection unit (ANSR UL639), UL Canada, C-Tick
