Alarm.com Cellular Flex IO Services (for 6 Sensors)
* This Cellular Flex IO Monitoring Bundle is an Add-On Service that requires either an existing Alarm.com PRO or DIY monitoring plan powered by GeoArm.
Alarm.com Flex IO Service Description:
The Alarm.com Cellular Flex IO Services enable new levels of flexibility for monitoring valuable property and assets anywhere that AT&T or Verizon cellular LTE connectivity is available. Whether used with a backyard gate or a remote storage unit, the Alarm.com Flex IO empowers users to keep an eye on what matters most. It can be used with the included magnet to monitor doors, gates, and other entryways. It also comes equipped with input and output options for integrating compatible devices that lack long-range connectivity.
Product Features:
- Monitoring for six (6) Flex IO Cellular Sensors
- Detect open/close using magnetic reed switch
- Detect state change for third-party device using Loop Input
- Change state of third-party and device using Relay Output (requires DC power to support always-on cellular connection)
- Compatible with the AT&T Cellular LTE Network (Model Number: ADC-FLEX-100-AT)
- Compatible with the Verizon Cellular LTE Network (Model Number: ADC-FLEX-100-VZ)
- In-App Property Panic (can upgrade cellular sensor plan to utilize this panic feature)
Please Note: The Cellular Flex IO Bundle is an Add-On Service that requires either an existing Alarm.com PRO or DIY monitoring plan powered by GeoArm.
Alarm.com Flex IO Product Documents:
ADC-FLEX-100-AT Flex IO Sensor for AT&T Cellular LTE
• Data Sheet for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)• Installation Guide for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• Loop Input or Relay Output Installation for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• Pull Apart Installation Guide for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• Use Cases for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• Loop Input Wire Length Supported for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• Advanced Troubleshooting Using MobileTech for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
• LED Patterns and Troubleshooting for Alarm.com Flex IO Cellular AT&T LTE Long-Range Property Sensor (ADC-FLEX-100-AT)
ADC-FLEX-100-VZ Flex IO Sensor for Verizon Cellular LTE
• Data Sheet for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)• Installation Guide for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• Loop Input or Relay Output Installation for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• Pull Apart Installation Guide for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• Use Cases for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• Loop Input Wire Length Supported for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• Advanced Troubleshooting Using MobileTech for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
• LED Patterns and Troubleshooting for Alarm.com Flex IO Cellular Verizon LTE Long-Range Property Sensor (ADC-FLEX-100-VZ)
Alarm.com Flex IO Product Specifications:
- Main Unit Dimensions: 6.8 x 2.2 x 1.3" (17.3 x 5.6 x 3.3 cm)
- Magnet Dimensions: 3.1 x 0.68 x 0.87" (7.9 x 1.7 x 2.2 cm)
- Power: Works with DC-wired power or battery power (battery backup recommended for wired installations).
- Power Requirements: 6 to 15 VDC supply. Minimum 1 A.
- Battery Power: Four 1.5 V AA lithium batteries (iron disulfide). 2+ years of battery life, depending on battery chemistry and operating temperature.
- Cellular Communication: AT&T LTE Network (ADC-FLEX-100-AT) or Verizon LTE Network (ADC-FLEX-100-VZ)
